ABB ControlMaster CM10 Manual

ControlMaster CM10, CM15, CM30, CM50, CMF160 and CMF310
Universal process controllers and indicator,
1
/8,
1
/4,
1
/2 DIN and fieldmount 6 MODBUS Tables
20 IM/CM/C–EN Rev. H
33 Relay 1
34 Relay 2
35 Relay 3
36 Relay 4
37 Totalizer 1 Intermediate Pulse
38 Totalizer 1 Wrap Pulse
39 Totalizer 2 Intermediate Pulse
40 Totalizer 2 Wrap Pulse
41 Logic Equation 1 State
42 Logic Equation 2 State
43 Logic Equation 3 State
44 Logic Equation 4 State
45 Logic Equation 5 State
46 Logic Equation 6 State
47 Logic Equation 7 State
48 Logic Equation 8 State
49 Realtime Alarm 1 State
50 Realtime Alarm 2 State
51 Alarm 1 State
52 Alarm 1 Ack State
53 Alarm 2 State
54 Alarm 2 Ack State
55 Alarm 3 State
MODBUS Coil Title
56 Alarm 3 Ack State
57 Alarm 4 State
58 Alarm 4 Ack State
59 Alarm 5 State
60 Alarm 5 Ack State
61 Alarm 6 State
62 Alarm 6 Ack State
63 Alarm 7 State
64 Alarm 7 Ack State
65 Alarm 8 State
66 Alarm 8 Ack State
67 Loop Break 1 State
68 Loop Break 2 State
69 Delay Timer 1 State
70 Delay Timer 2 State
89 Motorized Valve Output 1 Relay Close State
90 Motorized Valve Output 1 Relay Open State
91 Motorized Valve Output 1 Valve Sticking State
92 Motorized Valve Output 2 Relay Close State
93 Motorized Valve Output 2 Relay Open State
94 Motorized Valve Output 2 Valve Sticking State
95 Loop 1 Autotune In Progress
96 Loop 2 Autotune In Progress
MODBUS Coil Title

ABB ControlMaster CM10 Specifications

General

Brand	ABB
Model	ControlMaster CM10
Category	Controller
Language	English
