ControlMaster CM10, CM15, CM30, CM50, CMF160 and CMF310
Universal process controllers and indicator,
1
/8,
1
/4,
1
/2 DIN and fieldmount 6 MODBUS Tables
24 IM/CM/C–EN Rev. H
6.5.3 Input Registers For Bytes (MODBUS
Function Code 04 [Read Input Registers])
6.6 Holding Registers (MODBUS Function Code
03 [Read Holding Register] or 06 [Write Holding
Register])
6.6.1 Writable 16 Bits
6.6.2 Writable 32 Bits
MODBUS Register Title
0001 Output 1
0002 Output 2
0003 Instrument Type
0004 Instrument I/O build
0005 Instrument Functionality
MODBUS Register Title
2001 Alarm 1 Time Hysteresis
2002 Alarm 2 Time Hysteresis
2003 Alarm 3 Time Hysteresis
2004 Alarm 4 Time Hysteresis
2005 Alarm 5 Time Hysteresis
2006 Alarm 6 Time Hysteresis
2007 Alarm 7 Time Hysteresis
2008 Alarm 8 Time Hysteresis
MODBUS Register Title
6001 Totalizer 1 Preset Value
6003 Totalizer 1 Predetermined Value
6005 Totalizer 1 Intermediate Value
6007 Totalizer 2 Preset Value
6009 Totalizer 2 Predetermined Value
6011 Totalizer 2 Intermediate Value
