ControlMaster CM10, CM15, CM30, CM50, CMF160 and CMF310
Universal process controllers and indicator,
1
/8,
1
/4,
1
/2 DIN and fieldmount 7 Ethernet Connections
28 IM/CM/C–EN Rev. H
7 Ethernet Connections
7.1 CM10, CM15, CM30 and CM50
Standard Connections
Rear
View
Rear
View
CM10
CM15
CM30
CM50
Remove existing terminal screws
and screw the Ethernet adaptor
connection to the terminal numbers
shown above
Ethernet Adaptor
to Terminal
Connections
Ethernet
Socket
