ABB ControlMaster CM10 Manual

ControlMaster CM10, CM15, CM30, CM50, CMF160 and CMF310
Universal process controllers and indicator,
1
/8,
1
/4,
1
/2 DIN and fieldmount 6 MODBUS Tables
IM/CM/C–EN Rev. H 19
6MODBUS Tables
6.1 Input Coils – Digital Inputs (MODBUS Function Code 02 [Read Input Status])
Note. The tables in Section 6 contain MODBUS register numbers, not PDU addresses.
MODBUS Coil Title
1 Analog Input 1 Fail
2 Analog Input 2 Fail
3 Analog Input 3 Fail
4 Analog Input 4 Fail
5 Analog Input 1 (digital) Value
6 Analog Input 2 (digital) Value
7 Analog Input 3 (digital) Value
8 Analog Input 4 (digital) Value
9 Math Block 1 Fail
10 Math Block 2 Fail
11 Math Block 3 Fail
12 Math Block 4 Fail
13 Math Block 5 Fail
14 Math Block 6 Fail
15 Math Block 7 Fail
16 Math Block 8 Fail
17 Custom Linearizer 1 Fail
18 Custom Linearizer 2 Fail
19 Loop 1 Setpoint 1 Active
20 Loop 2 Setpoint 1 Active
21 Loop 1 Setpoint 2 Active
22 Loop 2 Setpoint 2 Active
23 Loop 1 Setpoint 3 Active
24 Loop 2 Setpoint 3 Active
25 Loop 1 Setpoint 4 Active
26 Loop 2 Setpoint 4 Active
27 Digital Output 1
28 Digital Output 2
29 Digital Output 3
30 Digital Output 4
31 Digital Output 5
32 Digital Output 6
MODBUS Coil Title
