ControlMaster CM10, CM15, CM30, CM50, CMF160 and CMF310
Universal process controllers and indicator,
1
/8,
1
/4,
1
/2 DIN and fieldmount 6 MODBUS Tables
IM/CM/C–EN Rev. H 23
5035 Loop 2 Feedforward Value
5041 Loop 1 Manual Valve Output
5045 Loop 2 Manual Valve Output
5043 Loop 1 Actual Valve Position
5047 Loop 2 Actual Valve Position
5049 Loop 1 Actual Ratio
5051 Loop 2 Actual Ratio
5053 Loop 1 Remote Setpoint
5055 Loop 2 Remote Setpoint
5057 Loop 1 Split Output 1
5059 Loop 1 Split Output 2
5061 Loop 2 Split Output 1
5063 Loop 2 Split Output 2
5065 Process Variable 1 Max
5067 Process Variable 2 Max
5069 Process Variable 1 Min
5071 Process Variable 2 Min
5073 Process Variable 1 Ave
5075 Process Variable 2 Ave
5077 Volume 1
5079 Volume 2
5081 Custom Linearizer 1 Value
5083 Custom Linearizer 2 Value
5085 Math Block 1 Result
MODBUS Register Title
5087 Math Block 2 Result
5089 Math Block 3 Result
5091 Math Block 4 Result
5093 Math Block 5 Result
5095 Math Block 6 Result
5097 Math Block 7 Result
5099 Math Block 8 Result
5101 Loop 1 Active Local Setpoint
5103 Loop 2 Active Local Setpoint
5105 Loop 1 Control Setpoint
5107 Loop 2 Control Setpoint
MODBUS Register Title
