ABB DCS 500B

DCS500 Pin and Parameter list
A 28
[ACK_MOTOR_FAN]
Input of DRIVE LOGIC-function block. ( S3/16 )
An acknowledge signal from motor fan contactor. The drive will not start if there is no
acknowledge from the motor fan contactor after the FAN_ON (10908)-command.
911 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10703 U: -
[ACK_MAIN_CONT]
Input of DRIVE LOGIC-function block. ( S3/16 )
An acknowledge signal from main contactor. The drive will not start if there is no
acknowledge from the main contactor after the MAIN_CONT_ON (10910)-command.
912 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10705 U: -
[MOTOR 2]
Input of DRIVE LOGIC-function block. ( S3/16 )
This signal activates the second parameter set. The drive has two parameter sets in the
memory. Active parameter set is selected with this signal:
0 = Parameter set nr. 1
<>0 = Parameter set nr. 2
913 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
FIELD_HEAT_SEL
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects if field heating is used when the drive is not running:
0 = DISABLE
1 = ENABLE
914 FB_P: E2 SC: - HL: 1 LL: 0 D: 0 U: -
MAIN_CONT_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects the command used to control the main contactor:
0 = CLOSE WHEN ON + RUN (both ON and RUN needed)
1 = CLOSE WHEN ON
915 FB_P: E2 SC: - HL: 1 LL: 0 D: 1 U: -
STOP_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects the operation when RUN-command is removed:
0 = STOP BY RAMP (decelerate with ramp generator)
1 = STOP BY TORQ LIM (decelerate with torque limit)
2 = STOP BY COASTING (make a coast stop)
916 FB_P: E2 SC: - HL: 2 LL: 0 D: 0 U: -
EME_STOP_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects the operation when emergency stop-command is activated:
0 = STOP BY RAMP (decelerate with ramp generator)
1 = STOP BY TORQ LIM (decelerate with torque limit)
2 = STOP BY COASTING (make a coast stop)
3 = STOP BY DYN.BRAKE (use dynamic braking)
917 FB_P: E2 SC: - HL: 3 LL: 0 D: 0 U: -
