ABB DCS 500B

DCS500 Pin and Parameter list
A 29
PANEL_DISC_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects the operation when the panel or CMT communication is disconnected during local
operation:
0 = STOP BY RAMP (decelerate with ramp generator)
1 = STOP BY TORQ LIM (decelerate with torque limit)
2 = STOP BY COASTING (make a coast stop)
3 = STOP BY DYN.BRAKE (use dynamic braking)
4 = CONTINUE REMOTE (change to remote control)
918 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
PWR_LOSS_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Selects if the auto-reclosing function is used when the power is disconnected for a short
time:
0 = DISABLE
1 = ENABLE
919 FB_P: E2 SC: - HL: 1 LL: 0 D: 0 U: -
COMFAULT_MODE
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Specifies the reaction of the drive after occurrance of a communication fault.
When a fieldbus communication module detects a communication fault these reaction
of the DCS 500 can be selected:
0 = STOP BY RAMP (decelerate with ramp generator)
1 = STOP BY TORQ LIM (decelerate with torque limit)
2 = STOP BY COASTING (make a coast stop)
3 = NOTHING (no action)
920 FB_P: E2 SC: - HL: 3 LL: 0 D: 0 U: -
COMFAULT_TIMEOUT
Parameter of DRIVE LOGIC-function block. ( S3/16 )
Sets sets the communication timeout counter.
It can be adjusted in 20 ms steps from
0 = disable fieldbus timeout (F60) supervision
1 = 1 * 20 ms to
150 = 150 * 20 ms = 3 sec
921 FB_P: I2 SC: 20 HL: 150 LL: 0 D: 2 U: ms
