DCS500 Pin and Parameter list
A 76
AI4:ERR
Signal of AI4-function block. ( S11/16 )
Status of AI4-function block:
0 = NO FAULT No fault
1 = I < 4 mA AI4_CONV_MODE = 2 and I < 4 mA,
current signal out of range
2 = NO IOB1/IOB2/IOB3 No IOB3-board connected
3 = WRONG IOB Only IOB2 connected or
AI4_CONV_MODE=3 and IOB3 not connected
4 = LOW VAL>HIGH VALAI4_LOW_VALUE > AI4_HIGH_VALUE.
10115 FB_O: E2 SC: - HL: - LL: - D: - U: -
AI5:OUT+
Signal of AI5-function block. ( S11/16 )
Value read from Analog Input 5.
10116 FB_O: I2 SC: - HL: - LL: - D: - U: -
AI5:OUT-
Signal of AI5-function block. ( S11/16 )
Value read from Analog Input 5. Negated output.
10117 FB_O: I2 SC: - HL: - LL: - D: - U: -
AI5:ERR
Signal of AI5-function block. ( S11/16 )
Status of AI5-function block:
0 = NO FAULT No fault
1 = I < 4 mA AI5_CONV_MODE = 2 and I < 4 mA,
current signal out of range
4 = LOW VAL>HIGH VALAI5_LOW_VALUE > AI5_HIGH_VALUE
5 = NO IOE1 No IOE1-board connected.
10118 FB_O: E2 SC: - HL: - LL: - D: - U: -
AI6:OUT+
Signal of AI6-function block. ( S11/16 )
Value read from Analog Input 6.
10119 FB_O: I2 SC: - HL: - LL: - D: - U: -
AI6:OUT-
Signal of AI6-function block. ( S11/16 )
Value read from Analog Input 6. Negated output.
10120 FB_O: I2 SC: - HL: - LL: - D: - U: -
AI6:ERR
Signal of AI6-function block. ( S11/16 )
Status of AI6-function block:
0 = NO FAULT No fault
1 = I < 4 mA AI6_CONV_MODE = 2 and I < 4 mA,
current signal out of range
4 = LOW VAL>HIGH VALAI6_LOW_VALUE > AI6_HIGH_VALUE
5 = NO IOE1 No IOE1-board connected.
10121 FB_O: E2 SC: - HL: - LL: - D: - U: -
DATASET1:OUT1
Signal of DATASET1-function block ( S12/16 )
DATASET 1 is used for data transmission from the fieldbus master to the drive.
When a fieldbus communication module is connected the DCS 500 can receive a
3 word telegram called DATASET1:OUT1…OUT3 from a fieldbus master.
DATASET1:OUT1 is the first word of this telegram.
10122 FB_O: I2 SC: - HL: - LL: - D: - U: -
