ABB DCS 500B

DCS500 Pin and Parameter list
A 77
DATASET1:OUT2
Signal of DATASET1-function block ( S12/16 )
DATASET1:OUT2 is the first word of this telegram.
10123 FB_O: I2 SC: - HL: - LL: - D: - U: -
DATASET1:OUT3
Signal of DATASET1-function block ( S12/16 )
DATASET1:OUT3 is the first word of this telegram.
10124 FB_O: I2 SC: - HL: - LL: - D: - U: -
DATASET3:OUT1
Signal of DATASET3-function block ( S12/16 )
DATASET 3 is used for data transmission from the fieldbus master to the drive.
When a fieldbus communication module is connected the DCS 500 can receive a
3 word telegram called DATASET3:OUT1...OUT3 from a fieldbus master.
DATASET3:OUT1 is the first word of this telegram.
10125 FB_O: I2 SC: - HL: - LL: - D: - U: -
DATASET3:OUT2
Signal of DATASET3-function block ( S12/16 )
DATASET3:OUT2 is the first word of this telegram.
10126 FB_O: I2 SC: - HL: - LL: - D: - U: -
DATASET3:OUT3
Signal of DATASET3-function block ( S12/16 )
DATASET3:OUT3 is the first word of this telegram.
10127 FB_O: I2 SC: - HL: - LL: - D: - U: -
