ABB DCS 500B

DCS500 Pin and Parameter list
A 111
CUR,FLX,VLT 100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal positive current, flux and voltage = 4095.
12512 FB_O: I2 SC: - HL: 4095 LL: 4095 D: 4095 U: -
CUR,FLX,VLT -100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal negative current, flux and voltage = -4096.
12513 FB_O: I2 SC: - HL: -4095 LL: -4095 D: -4096 U: -
SPEED: 100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal positive speed = 20000.
12514 FB_O: I2 SC: - HL: 20000 LL: 20000 D: 20000 U: -
SPEED: -100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal negative speed = -20000.
12515 FB_O: I2 SC: - HL: -20000 LL: -20000 D: -20000 U: -
SIG1(SPEED REF)
Signal of FREE_SIGNALS-function block ( S2,S16/16 )
This block is containing signals which can be set by the CMT or panel.
Value which can be used to give a speed reference. Before the drive will follow this
reference, it has to be connected to the speed reference input ERR.[IN] (2001).
12516 FB_O: I2 SC: - HL: 30000 LL: -30000 D: 0 U: -
SIG2(SPEED STEP)
Signal of FREE_SIGNALS-function block ( S2,S16/16 )
This block is containing signals which can be set by the CMT or panel.
Value which can be used to give a speed step. Before the drive will follow this step, it has
to be connected to the speed step input ERR.[STEP] (2002).
12517 FB_O: I2 SC: - HL: 30000 LL: -30000 D: 0 U: -
SIG3(TORQ. REF A)
Signal of FREE_SIGNALS-function block ( S2,S16/16 )
This block is containing signals which can be set by the CMT or panel.
Value which can be used to give a torque reference. Before the drive will follow this
reference, it has to be connected to the torque reference input SEL1.[TREF_A] (2401).
12518 FB_O: I2 SC: - HL: 30000 LL: -30000 D: 0 U: -
SIG4(TORQ. REF B)
Signal of FREE_SIGNALS-function block ( S2,S16/16 )
This block is containing signals which can be set by the CMT or panel.
Value which can be used to give a torque reference. Before the drive will follow this
reference, it has to be connected to the torque reference input SEL1.[TREF_B] (2404).
12519 FB_O: I2 SC: - HL: 30000 LL: -30000 D: 0 U: -
SIG5(TORQUE STEP)
Signal of FREE_SIGNALS-function block ( S2,S16/16 )
This block is containing signals which can be set by the CMT or panel.
Value which can be used to give a torque step. Before the drive will follow this step, it has
to be connected to the torque step input SEL2.[TORQ_STEP] (2409).
12520 FB_O: I2 SC: - HL: 30000 LL: -30000 D: 0 U: -
