Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions IV F 2 - 3
Internal signal connections
The software of the units series DCS 600 is divided into two parts which are handled
by processors integrated in the respective boards
SDCS-CON-2 (Software 15.2xx) and
SDCS-AMC-DC (Software 15.6xx).
The upload of signals from SDCS-CON-2 to SDCS-AMC-DC board are operated by:
• 6 automatic channels
• 11 programmable channels, selectable in group 94 (see Software description - chapter
31)
The 6 automatic channels are used by the functions:
• Display signals at control panel CDP 312
• Monitor signals at DriveWindow Tool
• Data Logger at DriveWindow Tool
If
• more than 6 signals of the SDCS-CON-2 board are selected, or
• the function Signals and Parameter of DriveWindow, or
• the overriding control (AC 80, AC 70…)
is used for monitoring, the signals should be selected in group 94.xx
Note: In the below mentioned tables
AMC / CON-2 will be used as type designations
instead of
SDCS-AMC-DC / SDCS-CON-2.
•
Fixed (defined) values
Cyclic transmission is used for fixed values. Fixed values are:
Cyclic transmission Parameter Function Cyclic trans-
from
--> to mission time
AMC --> CON-2  Internal Control Word 2 ms
AMC --> CON-2  Reserved 2 ms
AMC --> CON-2 2.13 Torque reference value 2 ms
AMC --> CON-2
5.06 Analogue output 1 2 ms
AMC --> CON-2
5.07 Analogue output 2 2 ms
AMC --> CON-2  Local reference 3 8 ms
