Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions
IV F
2 - 21
45.01 = decrease so that RL EMF VOLT ACT (1.17) is 70%.
Flux and thus the field current as well are reduced.
Proceed as described in (1. / 2. / 3.) above!
Read out and note down value of:
3.19 = ......... % (value for 41.15; will later be entered)
45.01 = decrease so that RL EMF VOLT ACT (1.17) is 40%.
Flux and thus the field current as well are reduced.
Proceed as described in (1. / 2. / 3.) above!
Read out and note down value of:
3.19 = ......... % (value for 41.14; will later be entered)
Stop the drive and switch OFF power!
45.01 = 100 %
46.01 = 10
46.02 = - 99
46.07 = SEL REF
As-delivered values (default values) for all 4 parameters restored.
41.19 = ? reference armature voltage scaled to Supply voltage
41.16 = enter the 1st noted down value of 3.19
41.15 = enter the 2nd noted down value of 3.19
41.14 = enter the 3rd noted down value of 3.19
Linearization function matched to field circuit.
99.02 = 90 % of the rated motor voltage.
99.05 = 90 % of the value on the motor rating plate.
These settings provide a bigger safety margin for the motor voltage during start-up.
Only if analog tacho is used as speed feedback!
Switch ON power; start drive.
DANGER: System components now energized!
Increase the reference value in LOCAL mode slowly up to maximum speed.
Check motor voltage; if value has been set with 99.02, motor voltage must
remain constant, or must not exceed this value.
Measure speed with manual tacho; balance maximum speed with Potentiometer
R2716 [on SDCS-CON-2 board] or R9 [on PS5311 board].
Stop the drive and switch OFF power!
