ABB DCS880 Manual

10
Introduction to this manual
3ADW000803R0101 DCS880 H4T (Tosa) manual en a
Term/Abbreviation
Definition
FENA-21
Optional dual-port Ethernet/IP, Modbus/TCP and PROFINET IO adapter.
FEPL-02
Optional POWERLINK adapter.
FIO-01
Optional digital I/O extension module.
FIO-11
Optional analog I/O extension module.
FPBA-01
Optional PROFIBUS DP adapter.
FPTC-01
Optional thermistor protection module.
FPTC-02 Optional ATEX-certified thermistor protection module for potentially explosive
atmospheres.
FSCA-01
Optional Modbus/RTU adapter.
FSO-21
Optional safety functions module.
FSPS-21
Optional PROFIsafe safety functions module.
HTL
High-threshold logic.
I/O
Input/Output.
ModuleBus
A communication link used by, for example, ABB controllers. DCS880 drives/units
can be connected to the optical ModuleBus link of the controller.
Network control
With fieldbus protocols based on the Common Industrial Protocol (CIP
TM
), such as
DeviceNet and Ethernet/IP, denotes the control of the drive/unit using the Net
Ctrl and Net Ref objects of the ODVA AC/DC Drive Profile. For more information,
see
www.odva.org, and the following manuals:
− FDNA-01 DeviceNet adapter module User’s manual (3AFE68573360).
− FENA-11/-21 Ethernet adapter module User’s manual (3AUA0000093568).
Off3 (emergency
stop)
Function in Drive:
Off3 (emergency stop) with configurable deceleration time according to cat. 1.
OPL Optical power link. Protocol used in communication between the control unit and
the power unit.
Parameter
User-adjustable operation instruction to the drive/unit.
PID controller
Proportional-integral-derivative controller. The speed control is based on a PID
algorithm.
PLC
Programmable logic controller.
Power unit
Contains the power electronics and power connections of the drive/unit. The
control unit is connected to the power unit.
PTC
Positive temperature coefficient.
PU
See power unit.
RFG
Ramp function generator.
RO
Relay output; interface for a digital output signal. Implemented with a relay.
Signal Value measured or calculated by the drive/unit. It can also contain status
information. Most signals are read-only, but some (especially counter-type
signals) can be reset.
SS1
Safe stop 1.
SSI
Synchronous serial interface.
STO
Safe torque off.
TTL
Transistor-transistor logic.
UPS
Uninterruptible power supply: Power supply equipment with battery to maintain
output voltage during power failure.

ABB DCS880 Specifications

General

Control Type	Digital
Voltage Range	Up to 1200 V DC
Control Principle	Field-oriented control
Field Supply	Integrated
Communication Protocols	CANopen
Cooling	Air
Protection Class	IP00, IP20, IP21, IP54
Protection Features	Overvoltage, overtemperature, short circuit, earth fault
Rated Voltage	230 to 1200 V DC
Supply Voltage	380 ... 690 V AC
Input Voltage Range	230 to 690 V AC
Control Mode	Speed, Torque
