ABB FEF series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
OI/FEF/FEV/FEW–EN Rev. D 39
DN300 (12 in.) ASME B16.5 CLASS 150 485 (19.09) 500 (19.69) 231 (9.09) 317 (12.48) 352 (13.86) 128 (282)
ASME B16.5 CLASS 300 520 (20.47) 540 (21.26)
EN1092 – 1 PN10 445 (17.52) 500 (19.69)
EN1092 – 1 PN16 460 (18.11) 500 (19.69)
EN1092 – 1 PN25 485 (19.09) 540 (21.26)
EN1092 – 1 PN40 515 (20.28) 540 (21.26)
JIS 5K 430 (16.93) 500 (19.69)
JIS 10K 445 (17.52) 500 (19.69)
AS4087 PN14, PN16 455 (17.91) 500 (19.69)
AS2129 TABLE TABLE C D 455 (17.91) 500 (19.69)
AS2129 TABLE E 455 (17.91) 500 (19.69)
AS4087 PN21 490 (19.29) 500 (19.69)
AS2129 TABLE F 490 (19.29) 500 (19.69)
DN350 (14 in.) ASME B16.5 CLASS 150 535 (21.06) 550 (21.65) 257.5 (10.14) 346 (13.62) 376 (14.80) 100 (220)
ASME B16.5 CLASS 300 585 (23.03) 570 (22.44)
EN1092 – 1 PN10 505 (19.88) 550 (21.65)
EN1092 – 1 PN16 520 (20.47) 550 (21.65)
EN1092 – 1 PN25 555 (21.85) 570 (22.44)
EN1092 – 1 PN40 580 (22.83) 570 (22.44)
JIS 5K 480 (18.90) 550 (21.65)
JIS 7.5K 530 (20.87) 550 (21.65)
JIS 10K 490 (19.29) 550 (21.65)
AS4087 PN14, PN16 525 (20.67) 550 (21.65)
AS2129 TABLE C D E 525 (20.67) 550 (21.65)
AS4087 PN21 550 (21.65) 550 (21.65)
AS2129 TABLE F 550 (21.65) 550 (21.65)
AS4087 PN35 550 (21.65) 570 (22.44)
AS2129 TABLE H 550 (21.65) 570 (22.44)
DN375 (15 in.) AS4087 PN14, PN16 550 (21.65) 550 (21.65) 257.5 (10.14) 346 (13.62) 376 (14.80) 115 (253)
AS2129 TABLE C 550 (21.65) 550 (21.65)
AS4087 PN35 580 (22.83) 570 (22.44)
DN400 (16 in.) ASME B16.5 CLASS 150 600 (23.62) 600 (23.62) 285 (11.22) 371 (14.61) 420 (16.54) 115 (253)
ASME B16.5 CLASS 300 650 (25.59) 620 (24.41)
EN1092 – 1 PN10 565 (22.24) 600 (23.62)
EN1092 – 1 PN16 580 (22.83) 600 (23.62)
EN1092 – 1 PN25 620 (24.41) 620 (24.41)
EN1092 – 1 PN40 660 (25.98) 620 (24.41)
JIS 5K 540 (21.26) 600 (23.62)
JIS 7.5K 582 (22.91) 600 (23.62)
JIS 10K 560 (22.05) 600 (23.62)
AS4087 PN14, PN16 580 (22.83) 600 (23.62)
AS2129 TABLE C D E 580 (22.83) 600 (23.62)
AS4087 PN21 610 (24.02) 600 (23.62)
AS2129 TABLE F 610 (24.02) 600 (23.62)
AS4087 PN35 610 (24.02) 620 (24.41)
AS2129 TABLE H 610 (24.02) 620 (24.41)
Dimensions in mm (in.)
DN Mating flange type D L C G A Approx. weight in kg (lb)
Table 5.5 DN80 to 600 (3 to 24 in. NB) (FEF) dimensions / weights (Continued)
