Electromagnetic flowmeters | Full-bore flow sensors 5 Sensor dimensions
40 OI/FEF/FEV/FEW–EN Rev. D
DN450 (18 in.) ASME B16.5 CLASS 150 635 (25.00) 700 (27.56) 317.5 (12.50) 402 (15.83) 480 (18.90) 160 (352)
ASME B16.5 CLASS 300 710 (27.95)
EN1092 – 1 PN10 615 (24.21)
EN1092 – 1 PN16 640 (25.20)
EN1092 – 1 PN25 670 (26.38)
EN1092 – 1 PN40 685 (26.97)
JIS 5K 605 (23.82)
JIS 7.5K 652 (25.67)
JIS 10K 620 (24.41)
AS4087 PN14, PN16 640 (25.20)
AS2129 TABLE C D 640 (25.20)
AS2129 TABLE E 640 (25.20)
AS4087 PN21 675 (26.57)
AS2129 TABLE F 675 (26.57)
AS4087 PN35 675 (26.57)
AS2129 TABLE H 675 (26.57)
DN500 (20 in.) ASME B16.5 CLASS 150 700 (27.56) 770 (30.31) 345 (13.58) 429 (16.89) 520 (20.47) 217 (455)
ASME B16.5 CLASS 300 775 (30.51)
EN1092 – 1 PN10 670 (26.38)
EN1092 – 1 PN16 715 (28.15)
EN1092 – 1 PN25 730 (28.74)
EN1092 – 1 PN40 755 (29.72)
JIS 5K 655 (25.79)
JIS 7.5K 706 (27.80)
JIS 10K 675 (26.57)
AS4087 PN 14, PN16 705 (27.76)
AS2129 TABLE C D E 705 (27.76)
AS4087 PN21 735 (28.94)
AS2129 TABLE F 735 (28.94)
AS4087 PN35 735 (28.94)
AS2129 TABLE H 735 (28.94)
DN600 (24 in.) ASME B16.5 CLASS 150 815 (32.09) 920 (36.22) 387.5 (15.25) 472 (18.58) 610 (24.02) 315 (693)
ASME B16.5 CLASS 300 915 (36.02)
EN1092 – 1 PN10 780 (30.71)
EN1092 – 1 PN16 840 (33.07)
EN1092 – 1 PN25 845 (33.27)
EN1092 – 1 PN40 890 (35.04)
JIS 5K 770 (30.31)
JIS 7.5K 810 (31.89)
JIS 10K 795 (31.30)
AS4087 PN14, PN16 825 (32.48)
AS2129 TABLE C D 825 (32.48)
AS2129 TABLE E 825 (32.48)
AS4087 PN21 850 (33.46)
AS2129 TABLE F 850 (33.46)
AS4087 PN35 850 (33.46)
AS2129 TABLE H 850 (33.46)
Dimensions in mm (in.)
DN Mating flange type D L C G A Approx. weight in kg (lb)
Table 5.5 DN80 to 600 (3 to 24 in. NB) (FEF) dimensions / weights (Continued)
