ABB GOE 2600 - Page 21

Installation and commissioning guide
1ZSC000563-AAF EN, REV. 4, 2021-06-23
21
2. Remove the M10 bolts (6), and then remove the
outer terminal (5).
G004691
3.
Place the lifting tool, lower part (1) around the
porcelain.
NOTE!
Make sure the rubber protection
protect the bushing.
G006984
4.
Close the lifting tool (1) and install the bolts.
NOTE!
Align the side of the lifting tool with the
oil-level guage (26).
G006985
