Installation and commissioning guide
1ZSC000563-AAF EN, REV. 4, 2021-06-23
7
2 Product description
2.1 Design
Overview
The GOE 2600 is a capacitance graded oil impregnated paper bushing made for immersed oil/air service.
General schematics
G006945
9 Oil plug
26 Oil-level gauge
36 Bottom contact
51 Oil sampling valve ½”
65 Mounting flange
68 Top housing
69 Porcelain insulator, air side
70 Test tap
71 Extension for current transformer
72 Porcelain insulator, oil side
74 Lifting eye Ø 70 mm
