ABB GOE 2600 - Page 26

26
Installation and commissioning guide
1ZSC000563-AAF EN, REV. 4, 2021-06-23
5. Loosen the nut (44).
G005067
6.
Turn the shaft (37) counter clockwise to remove the shaft-socket from the upper draw rod (35).
7.
Remove the hydraulic jack (38) from the bushing.
G005068
8.
Apply Molykote Multilub to the threads on the
pull-through cord(12), then connect it to the upper
drawrod.
NOTE!
The terminal on the pull-through
cord(12) has M8 threads.
NOTE!
Or use a lubricant with equal properties
to Molykote Multilub.
G006960
