72
Installation and commissioning guide
1ZSC000563-AAF EN, REV. 4, 2021-06-23
5. Remove the lifting tool (88).
G007208
6.
Attach the bushing to the transport box in the same way as when it was delivered.
CAUTION!
Make sure that the bushing cannot move or rotate in the transport box.
7.
Close the transport box.
NOTE!
Refer to Lifting the transport box, page 14 and Transportation, page 13.
End of instruction
