Operation Manual / 4 Product description / A130-H.. - A140-H
12 Spare parts / 12.3 View of turbocharger with part numbers
© Copyright 2020 ABB. All rights reserved. HZTL4030_EN Rev.F February 2020
Part number Designation
10900 Cartridge group
42008 Socket screw
42012 (in customer spare part set) O-ring (high-temperature resisting, colour: red
or green)
42126** Graphite cord sealing
42201* Clamping nut
51000 Turbine casing
51002 Fastening strip
51105* Metal C-ring
51500 Burst protection
56001 Nozzle ring
56005 Lamellar sealing ring
57002 Gas outlet flange
57003* Metal C-ring
57210 Burst ring
61001 Gas outlet casing
61002 (in customer spare part set) Gasket
61200 Burst protection
61205 Protective grid
61301* Support
72000 Compressor casing
72011 Hexagon-head screw
72012 Fastening strip
72020 V-clamp
77000 Wall insert
77005 (in customer spare part set) O-ring
79000 Diffuser
79041 (in customer spare part set) Counter-sunk screw
81000 Filter silencer
81010 (in customer spare part set) O-ring
82000 Air suction branch
82010 (in customer spare part set) O-ring
86505* Speed sensor
86515* Cable connector
86526* F/I converter
86528* Tachometer
Table45: Spare parts list
* Depending on the specification of the turbocharger
** in some installations a special graphite cord sealing is fitted or can be fitted. This is a ser-
vice solution only in cases of unexpectedly high temperatures at the gasket. Please contact
ABB for further instructions.
Page 91 / 93
