2 Removing and Installing
2.1 Weight and transportation of the turbocharger
Lifting gear with a sufficient load limit must be used for removing, installing and transport-
ing the turbocharger. The weight specified below applies to the heaviest variant possible.
Depending on the specification, the weight specified on the rating plate may be lower than
the standard value specified here.
Fig.5: Transportation of the turbocharger
Product Weight of complete turbocharger unit [kg]
A130-H 190
A135-H 270
A140-H 460
Table2: Weight of complete turbocharger unit
Page 8 / 93
