4.4.3 Replacing the tubular spare parts
Location of tubular spare parts
The tubular parts that are considered spare parts are located as shown in the
figure.
Tubular cable hous-
ing cover
Tubular cable hous-
ing
Tubular coverTubular with sleeve
xx1400000435
xx1400000434xx1400000433
xx1400000432
3HAC059694-0013HAC059695-0013HAC049656-0013HAC059693-001 /
3HAC059723-001
i
:
3HAC056145-001:3HAC056143-001:3HAC056144-001 /
3HAC059708-001
ii
:
3HAC059706-001:
Used with protection
type Clean Room.
Used with protection
type Clean Room.
Used with protection
type Clean Room.
Used with protection
type Clean Room.
Used for robots with
food grade lubrica-
tion.
Used for robots with
food grade lubrica-
tion.
Used for robots with
food grade lubrica-
tion.
Used for robots with
food grade lubrica-
tion.
Replace if damaged.
Replace if damaged.
3HAC079690-001:3HAC079692-001:
Used with protection
type Hygienic.
3HAC079689-001:
Used with protection
type Hygienic.
3HAC079693-001:
Used with protection
type Hygienic.
Used with protection
type Hygienic.
Replace if damaged. Replace if damaged.
i
For information on which tubular to be ordered, see Spare part versions for the tubular on Type A
robots on page 881.
ii
For information on which tubular cover for Clean Room robots to be ordered, see Spare part versions
for the tubular cover on Clean Room robots on page 882.
Required spare parts
Note
The spare part numbers that are listed in the table can be out of date. See the
latest spare parts of the IRB 1200 via myABB Business Portal,
www.abb.com/myABB.
NoteArticle numberSpare part
3HAC059693-001 /
3HAC059723-001
i
Tubular with sleeve
Used with protection type Clean
Room.
Used for robots with food grade
lubrication.
3HAC059706-001Tubular with sleeve, Clean
Room
Tubular with sleeve, food grade
lubrication
Used with protection type Hy-
gienic.
3HAC079693-001Tubular with sleeve, Hygienic
Continues on next page
380 Product manual - IRB 1200
3HAC046983-001 Revision: S
© Copyright 2014 - 2021 ABB. All rights reserved.
4 Repair
4.4.3 Replacing the tubular spare parts
