ABB IRC5 Applications Manual

2 Machine Synchronization
2.3.1. Sensor installation
373HAC18154-1 Revision: F
© Copyright 2004-2008 ABB. All rights reserved.
How to add a sensor manually for Sensor Synchronization
Use the following procedure to add a sensor manually.
How to add a sensor manually for Analog Synchronization
There are no prepared files for adding a sensor for Analog Synchronization. It can be
accomplished by copying the following files and edit them for the second sensor:
• synvaileio.cfg
• synvailprc.cfg
• syim1.moc
Action
1. Connect the encoder interface unit to the CAN bus. Note the address on the CAN bus.
2. In RobotStudio, click Load Parameters.
3. Select: Load Parameters if no duplicates and click Open.
4. Installation of a master sensor, connected to DeviceNet1 (first board).
Load the following files one by one from the OPTIONS/CNV directory:
• syvm1_eio.cfg
• syvm1_prc.cfg
• syvm1_moc.cfg
5. Installation of a slave sensor, connected to DeviceNet2 (second board).
Load the following files one by one from the OPTIONS/CNV directory:
• syvs1_eio.cfg
• syvs1_prc.cfg
• syvs1_moc.cfg
6. Restart the system.
7. If necessary, correct the address for the new encoder interface units. The default
addresses in the file syvxx_eio.cfg should be replaced by the actual address of the
board.
Continued

ABB IRC5 Specifications

General

Type	Industrial Robot Controller
Model	IRC5
Protection Class	IP54
Power Supply	200-600 VAC, 50/60 Hz
Communication Protocols	PROFIBUS, PROFINET, DeviceNet
Programming Language	RAPID
Number of axes	Up to 36
Storage Temperature	-25°C to +55°C
Relative Humidity	95% (non-condensing)
