ABB IRC5 Applications Manual

2 Machine Synchronization
2.6.1. Introduction
633HAC18154-1 Revision: F
© Copyright 2004-2008 ABB. All rights reserved.
2.6 Synchronize with hydraulic press using recorded profile
2.6.1. Introduction
Overview
This section describes how to use a recorded machine profile to improve the accuracy of
robot’s synchronization with a hydraulic press. This profile is used for modeling of press path.
Not using a recorded profile will require a bigger distance between robot and press model
when teaching the path.
Principles of hydraulic press synchronization
1. Record the movement of the hydraulic press.
2. Activate the record to be used in the next cycle.
3. Activate the sensor synchronization with the RAPID instruction
SyncToSensor.

ABB IRC5 Specifications

General

Type	Industrial Robot Controller
Model	IRC5
Protection Class	IP54
Power Supply	200-600 VAC, 50/60 Hz
Communication Protocols	PROFIBUS, PROFINET, DeviceNet
Programming Language	RAPID
Number of axes	Up to 36
Storage Temperature	-25°C to +55°C
Relative Humidity	95% (non-condensing)
