ABB IRC5 Applications Manual

2 Machine Synchronization
2.5.3. Master robot configuration parameters
553HAC18154-1 Revision: F
© Copyright 2004-2008 ABB. All rights reserved.
MinLog -10.0
MinPhys -1
MinPhysLimit -1
MinBitVal -32767
EIO_SIGNAL/Parameters Value
Name ao1Speed
SignalType AO
Unit MASTER1
UnitMap 16-31
MaxLog 10.0
MaxPhys 1
MaxPhysLimit 1
MaxBitVal 32767
MinLog -10.0
MinPhys -1
MinPhysLimit -1
MinBitVal -32767
EIO_SIGNAL/Parameters Value
Name ao1PredTime
SignalType AO
Unit MASTER1
UnitMap 32-47
MaxLog 10.0
MaxPhys 1
MaxPhysLimit 1
MaxBitVal 32767
MinLog -10.0
MinPhys -1
MinPhysLimit -1
MinBitVal -32767
EIO_SIGNAL/Parameters Value
Name do1Dready
SignalType DO
Unit MASTER1
UnitMap 48
EIO_SIGNAL/Parameters Value
Name do1Sync2
SignalType DO
EIO_SIGNAL/Parameter Value
Continued
Continues on next page

ABB IRC5 Specifications

General

Type	Industrial Robot Controller
Model	IRC5
Protection Class	IP54
Power Supply	200-600 VAC, 50/60 Hz
Communication Protocols	PROFIBUS, PROFINET, DeviceNet
Programming Language	RAPID
Number of axes	Up to 36
Storage Temperature	-25°C to +55°C
Relative Humidity	95% (non-condensing)
