ABB M4M 20 - Versions; Overall Dimensions

10 M4M 20 NETWORK ANALYZER USER MANUAL
3.4.Versions
Product Name I/O Communication protocol
M4M 20 2 Digital Outputs Bluetooth
M4M 20 MODBUS 2 Digital Outputs Modbus RTU, Bluetooth
M4M 20-M MODBUS 2 Digital Outputs Modbus RTU, Bluetooth
M4M 20 ETHERNET 2 Digital Outputs Modbus TCP/IP, Bluetooth
M4M 20-M ETHERNET 2 Digital Outputs Modbus TCP/IP, Bluetooth
M4M 20 PROFIBUS 2 Digital Outputs Profibus DP-V0, Bluetooth
M4M 20 I/O
2 Programmable I/O
2 Digital Outputs
2 Analogue Outputs
Modbus RTU, Bluetooth
M4M 20 ROGOWSKI 2 Digital Outputs Modbus RTU, Bluetooth
M4M 20 BACNET 2 Digital Outputs BACnet/IP, Bluetooth
3.5.Overall dimensions
96 mm
96 mm
57 mm*
75,5 mm
77,5 mm*
92
-0+0,8
mm
92
-0+0,8
mm
*with terminal.
IEC 61554
