6.4.Overview of menu displays
Each section of the device contains different menus and submenus as per below tables:
→
Graphs
Menu Description
Realtime Graphs
Bargraphs for voltage (L-N, L-L), current, power (active, reactive,
apparent).
→
Data Reading
Menu Description
Realtime
Summary, voltage (L-N, L-L), current, power (active, reactive,
apparent), frequency.
Energy Active, reactive, apparent energy, import, export and net.
Power quality
THD (voltage, current), unbalances (voltage, current), power factor
and cosphi per each phase.
Average
Average values in the latest period for voltage, current power (active,
reactive, apparent).
Min value
Minimum values for voltage, current and demand power (active,
reactive, apparent).
Max value
Maximum values for voltage, current and demand power (active,
reactive, apparent).
I/O I/O status according to the I/O type and M4M version.
Notifications List of notifications divided into alarms, warnings, errors.
Timers Count-up timer (on hours), count-down timer (maintenance timer).
→
Menu Description
Unit Settings related to the device itself.
Installation Settings related to the installation conditions.
I/O Definition of I/O type of the M4M version.
Alarms
Definition of alarm conditions to be visualized as notifications or
linked to I/O.
Communication
Settings related to the embedded communication protocols of the
M4M version
Other settings Settings for average values, timers, energy conversion
