Note
If the desktop mounting kit is mounted to the controller, do not hold the TPU
connector (X4) during any moving or transporting of the controller.
Required equipment
InformationEquipment
3HAC063919-001Mounting kit
See Standard toolkit for controller on
page 456.
Standard toolkit
Procedure
Use this procedure to install the desktop mounting kit on the controller.
Info/illustrationAction
xx2400000035
Remove the top cover from the controller.1
Continues on next page
74 Product manual - OmniCore C30 Type A
3HAC089064-001 Revision: A
© Copyright 2024 ABB. All rights reserved.
3 Installation and commissioning
3.4.5 Mounting the controller with desktop mounting kit [3001-2]
Continued
