CAUTION
During this operation it is possible to over load the load cells if the operation is done not careful
enough, especially if the roll is heavy.
The most critical load cells are naturally the PFTL 101A-0.5 kN and PFTL 101B-2 kN.
Applications with inclined mounting are most critical.
6. Adjust the load cells so that they are in parallel with each other and in line with the axial direction
of the roll. Tighten the foundation screws, see Figure 15. Installation of Adapter Plates and Align-
ment of Load Cells page 21.
7. Adjust the roll so that it is at right angles to the longitudinal direction of the load cells.Tighten the
screws in the upper adapter plate, see Figure 15. Installation of Adapter Plates and Alignment of
Load Cells page 21.
Table 2 Tightening Torques for Load Cell PFTL 101
Option Type of screws Strength
class
Type of
lubrication
Dimension Tightening
torque
[Nm] ± 5%
1
(Recommended)
Alloyed steel
screws
Strength class
according to ISO
898/1
12.9 Oil M12 136
M16 333
M20 649
2
(Recommended)
Alloyed steel
screws
Strength class
according to ISO
898/1
12,9 MoS
2
M12 117
M16 286
M20 558
3 Stainless steel
(A2-80)
or acid resistant
steel (A4-80),
Strength class
according to ISO
3506
A2-80
or
A4-80
Wax M12 76
M16 187
M20 364
4 Stainless steel
(A2-80)
or acid resistant
steel (A4-80),
Strength class
according to ISO
3506
A2-80
or
A4-80
Oil
or
emulsion
M12 65
M16 161
M20 313
Pressductor PillowBlock Load Cells, Horizontal Measuring PFTL 101, User Manual
3 Installation
20 3BSE009965R0401 en Rev E
