B/BE/BER 125 125 125 125
Weight A/AE/AER 9 9 10 kg
B/BE/BER 20 21 21 23
Material A/AE/B/BE Stainless steel SIS 2383
DIN 17440 X12CrMoS17
Werkstoffnr 1.4104
AISI 430F
AER/BER Acid resistant steel:
DIN 17440 X2CrNiMo17 13 2
Werkstoffnr 1.4404
AISI 316L
Accuracy
Accuracy class A/AE/AER
B/BE/BER
± 0,5 %
Linearity deviation < ± 0,3
Repeatability error < ± 0,05
Hysteresis <0,2
Compensated temper-
ature range
+20 - +80 °C
Zero point drift
30 (80
2)
)
ppm/K
Sensitivity drift 150
Working temperature
range
-10 - +105 °C
Zero point drift
50 (100
1)
)
ppm/K
Sensitivity drift 250
Storage temperature
range
-40 - +105 °C
1) Denitions of directions designations “
V
”and “
A
” in F
V
and F
A
are given in 2.5.1 Coordinate System.
2) PFTL 101AER -0.5 kN/ -1.0 kN
2.3 Denitions
Nominal load
Nominal load, F
nom
, is the maximum load in the measurement direction for which the load cell is
dimensioned to measure within the
specied accuracy class. The load cell is calibrated up to F
nom
.
Sensitivity
Sensitivity is
dened as the difference in output values between nominal load and zero load.
Pressductor PillowBlock Load Cells, Horizontal Measuring PFTL 101, User Manual
2 Description
3BSE009965R0401 en Rev E 11
