ABB PFTL 101 - Cabling

Figure 3-1. Typical Installation
c
c
b
b
NOTE
Do not drill in this
B/BE/BER
Tubular
dowel pin
Ø a
Load cell PFTL 101
a b c
A/AE/AER 8
15
15
15
12
20
8.4
12.5
area, as internal
wiring may be
damaged.
Ø a
Ø a
Ø a
Ø
Ø
Ø
Figure 14. Typical Installation
Figure 3-2. Installation of Adapter Plates and Alignment of Load Cells
F
R
F
R
90°
Top view
Adapter plates
Thickness
PFTL 101A min. 30 mm
PFTL 101B min. 35 mm
A
A
Figure 15. Installation of Adapter Plates and Alignment of Load Cells
3.6 Cabling
The cable must not create shunting forces in the measuring direction of the
load cell e.g. forces caused by thermal expansion, gravity or similar.
Pressductor PillowBlock Load Cells, Horizontal Measuring PFTL 101, User Manual
3 Installation
3BSE009965R0401 en Rev E 21
