Tightening torques for HygienicMaster with variable process connections
Nominal diameter Maximum tightening torque
[mm] [in] [Nm]
DN 3 to DN 10 ⅜ in 8
DN 15 ½ in 10
DN 20 ¾ in 21
DN 25 1 31
DN 32 1 ¼ in 60
DN 40 1 ½ in 80
DN 50 2 5
DN 65 2 ½ in 5
DN 80 3 15
DN 100 4 14
Parameterization overview (factory settings)
Parameter Value range Factory setting
Sensor Tag Alphanumeric, maximum 20 characters. None
Sensor Location Tag Alphanumeric, maximum 20 characters. None
Qv Max 1 Depending on the nominal diameter of the sensor. Set to Q
max
DN in accordance with Measuring range
table on page 60.
Unit Volumeflow Qv l/s; l/min; l/h; ml/s; ml/min; m3/s; m3/min; m3/h; m3/d;
hl/h; g/s; g/min; g/h; kg/s; kg/min; kg/h; kg/d; t/min;
t/h; t/d
l/min
Unit Vol. Totalizer m3; l; ml; hl; g; kg; t Liter (l)
Pulses per Unit 1 to 10000 1
Pulse Width 0.1 to 2000 ms 100 ms
Damping 0.02 to 60 s 1
Operating mode Digital output 41 / 42 Off, Binary output, Pulse output, Frequency output Digital output 41/42 as pulse output for forward flow
and reverse flow
Operating mode Digital output 51 / 52 Off, Binary output, pulse output (follows digital output
41 / 42, 90 ° or 180 ° out of phase)
Digital output 51 / 52 as binary output for output of
the flow direction.
Curr.Out 31/32 4-20mA FWD/REV, 4-20mA FWD, 4-12-20 mA 4-20mA FWD/REV
Curr.Out at Alarm High Alarm 21 to 23 mA or Low Alarm 3.5 to 3.6 mA High Alarm, 21.8 mA
Current at flow rate> 103 % (I=20.5 mA) Off (current output remains at 20.5 mA), High Alarm, Low
Alarm ,
Off
Low flow cutoff 0 to 10 % 1 %
Empty pipe detection On / Off Off
