10 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D
… 2 Design and function
Model variants
ProcessMaster / HygienicMaster is available in two product
series.
FEP610 / FEH610 with base functionality
FEP630 / FEH630 with extended functions and options
Characteristics / Functions ProcessMaster HygienicMaster
FEP610 FEP630 FEH610 FEH630
Measuring accuracy
0.4 % (option 0.2 %) of measured
value
0.5 % of measured value
Explosion protection
Option with approval for
potentially explosive atmosphere
Optional diagnosis functions
Detecting gas bubbles,
conductivity monitoring,
temperature monitoring
Grounding check
With noise check functions
Detection of partially filled pipe
With partial fill electrode
– –
Liner and electrode material
optional
Ceramic carbide liner, tungsten
carbide electrodes, double-layer
electrodes
– –
Batch functions
Presetting counter, overrun
correction, external start/stop,
batch end contact
Optional nominal diameter
DN 1 to DN 2
– – –
Fieldbus
PROFIBUS DP®, Modbus®
Verification
Optional
Integral mount design
For devices with an integral mount design, the transmitter and
flowmeter sensor form a single mechanical unit.
Remote mount design
For devices with a remote mount design, the transmitter and
flowmeter sensor are mounted in separate locations.
The electrical connection between the transmitter and the
flowmeter sensor is provided by a signal cable.
A maximum signal cable length of 200 m (656 ft) is possible.
Notes on the ProcessMaster
The flowmeter sensor of the ProcessMaster is available in two
designs, which are distinguished by the design level (A / B).
Notes on the transmitter housing
The transmitter is available in two housing designs:
Single-compartment housing:
In the single-compartment housing, the electronics
chamber and the connection chamber in the transmitter
are not separated from each other.
Dual-compartment housing:
In the dual-compartment housing, the electronics
chamber and the connection chamber in the transmitter
are separated from each other.
