ABB PSTX 570 - Dimension Prints PSTX720

1SFC13105M0201 | Service Manual | Description 13
• PSTX720...840
• PSTX1050...1250
2.1.7 Dimension prints PSTX720...840, PSTX1050...1250
8 mm (0.315 in)
435 mm (17.126 in)
55.8 mm (2.2 in)
63 mm (25 in)
150.5 mm (5.93 in)
369 mm (14.5 in) 350 mm (13.8 in)
Ø 13 (4x)
Ø6.5 (12x)
Ø12.5 (6x)
490 mm (19.29 in)
408.9 mm (16.1 in)
460 mm (18.11 in) 493 mm (19.409 in)
40mm
(1.57 in)
72 mm
(2.8 in)
7 mm (0.276 in) 4x
7 mm (0.276 in) 4x
369 mm
(14.5 in)
565 mm (22.2 in)
515 mm (20.2 in)
485 mm (19 in)
435 mm (17.1 in)
62.6 mm
(2.46 in) 6x
8 mm
(0.3 in) 6x
367 mm (14.4 in)
150 mm (5.9 in) 2x
= Connection bars for PSTX1050
407 mm (16 in)
50 mm
(1.9 in) 6x
40 mm
(1.5 in) 6x
133.5 mm
(5.2 in) 2x
72 mm
(2.8 in) 4x
301.5 mm (11.8 in)
22.5 mm (0.8 in) 6x
1SFC132081M0201
Ø12.5 (6x)
Ø6.5 (12x)
Ø13 (4x)
Ø13 (18x)
2
