1SFC13105M0201 | Service Manual | Service PSTX720...840 39
8. Remove bypass contactor
1
Remove the bypass contactor from base plate.
Dispose of expended bypass contactor.
9. Place new bypass contactor
1
Place the new bypass contactor on the base
plate with terminals 2T1, 4T2 and 6T3 facing
downwards.
8
3.6.1_8
1
9
3.6.1_9
1
