1.2 Symbols and signs
In the manual and/or in some cases on the equipment, the danger or hazard zones/components are
indicated with signs, labels, symbols or icons.
Symbol Description
Note - General information about product
General warning - Important safety information. Indicates a potentially hazardous
situation which, if not avoided, could result in death or serious injury.
Dangerous Voltage - Indicates a potentially hazardous situation, in particular a high
voltage, which, if not avoided, could result in death or serious injury. The inverter has
high voltages and high energy levels.
Hot parts - Indicates a potentially hazardous situation related to hot surface, which, if
not avoided, could result in serious injury. Some surfaces in the inverter will become hot
during operation and must not be touched until the parts have cooled down.
Risk of injury due to the weight of the equipment. Take care during lifting and transport.
Indicates that the area must not be accessed or that the operation described must not
be carried out.
Keep out of the reach of children
Indicates that it is mandatory to carry out the described operations using the clothing
and/or personal protective equipment provided by the employer.
Indicates the connection point for protective earth.
Rated temperature range.
Indicates the discharge time of the stored energy (represented in the figure by the
letters XX), is provided on the identification label.
Direct Current
Alternate current
Without isolation transformer
Positive pole of the input voltage (DC)
Negative pole of the input voltage (DC)
Indicates the center of gravity of the equipment.
Indicates the requirement to wear acoustic protection devices in order to prevent
damage to hearing
