ABB rec670 Commissioning Manual

IEC 61850 ANSI Function description Bay control
REC670
(Customized)
REC670 (A30) REC670 (A31) REC670 (B30)
REC670 (C30)
RS485GEN RS485 1 1 1 1 1
DNPGEN DNP3.0 communication
general protocol
1 1 1 1 1
DNPGENTCP DNP3.0 communication
general TCP protocol
1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485
communication protocol
1 1 1 1 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and
EIA-485 communication
protocol
1
1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for serial
communication protocol
1 1 1 1 1
DNPFREC DNP3.0 fault records for
TCP/IP and EIA-485
communication protocol
1
1 1 1 1
IEC 61850-8-1 Parameter setting
function for IEC 61850
1 1 1 1 1
GOOSEINTLKRCV Horizontal
communication via
GOOSE for interlocking
59
59 59 59 59
GOOSEBINRCV GOOSE binary receive 16 16 16 16 16
GOOSEDPRCV GOOSE function block to
receive a double point
value
64
64 64 64 64
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand
value
60
60 60 60 60
GOOSESPRCV GOOSE function block to
receive a single point
value
64
64 64 64 64
GOOSEVCTRRCV Horizontal
communication via
GOOSE for VCTR
7
7 7 7 7
GOOSEVCTRCON
F
GOOSE VCTR
configuration for send
and receive
1
1 1 1 1
MULTICMDRCV,
MULTICMDSND
Multiple command and
transmit
60/10 60/10 60/10 60/10 60/10
FRONT, LANABI,
LANAB, LANCDI,
LANCD
Ethernet configuration of
links
1 1 1 1 1
Table continues on next page
1MRK 511 360-UEN A Section 3
Available functions
Bay control REC670 2.1 IEC 37
Commissioning manual
