ABB rec670 Commissioning Manual

IEC 61850 ANSI Function description Bay control
REC670
(Customized)
REC670 (A30) REC670 (A31) REC670 (B30)
REC670 (C30)
GATEWAY Ethernet configuration of
link one
1 1 1 1 1
OPTICAL103 IEC 60870-5-103 Optical
serial communication
1 1 1 1 1
RS485103 IEC 60870-5-103 serial
communication for
RS485
1
1 1 1 1
AGSAL Generic security
application component
1 1 1 1 1
LD0LLN0 IEC 61850 LD0 LLN0 1 1 1 1 1
SYSLLN0 IEC 61850 SYS LLN0 1 1 1 1 1
LPHD Physical device
information
1 1 1 1 1
PCMACCS IED Configuration
Protocol
1 1 1 1 1
SECALARM Component for mapping
security events on
protocols such as DNP3
and IEC103
1
1 1 1 1
FSTACCS
FSTACCSNA
Field service tool access
via SPA protocol over
ethernet communication
1
1 1 1 1
ACTIVLOG Activity logging
parameters
1 1 1 1 1
ALTRK Service Tracking 1 1 1 1 1
SINGLELCCH Single ethernet port link
status
1 1 1 1 1
PRPSTATUS Dual ethernet port link
status
1 1 1 1 1
Process bus
communication IEC
61850-9-2
1)
PRP IEC 62439-3 parallel
redundancy protocol
0-1 1-P03 1-P03 1-P03 1-P03
Remote communication
Binary signal transfer
receive/transmit
6/36 6/36 6/36 6/36 6/36
Transmission of analog
data from LDCM
1 1 1 1 1
Receive binary status
from remote LDCM
6/3/3 6/3/3 6/3/3 6/3/3 6/3/3
Scheme communication
ZCPSCH 85 Scheme communication
logic for distance or
overcurrent protection
0-1
1-K01 1-K01 1-K01 1-K01
Table continues on next page
Section 3 1MRK 511 360-UEN A
Available functions
38 Bay control REC670 2.1 IEC
Commissioning manual
