Variable Actual settings
(R), channel 0
Group/Channel 1
(R, W, P)
Group/Channel 2
(R, W, P)
Setting range
Time multiplier k
0
S14 1S14 2S14 0.05...1.00 s
Time multiplier n
0
S15 1S15 2S15 1.0…15.0
Resetting time of stage I
0
> S16 1S16 2S16 0.05...2.50
Start value of stage I
0
>> S17
a)
1S17 2S17 5.0...800% I
n
Operate time of stage I
0
>> S18 1S18 2S18 0.05...300 s
Start value of value of stage ΔI> S19
a)
1S19 2S19 10...100%
Operate time of stage ΔI> S20 1S20 2S20 1...300 s
Full load current S21
a)
1S21 2S21 0.30...1.50 x In
Time constant of stage θ> S22 1S22 2S22 1...200 min
Alarm level of stage θ> S23 1S23 2S23 50...100% θ
t
>
Operate time of CBFP S24 1S24 2S24 0.10...60.0 s
Number of AR shots S25 1S25 2S25 0 = AR is not in
use
1 = shot 1
2 = shot 1 and 2
3 = shot 1, 2 and
3
Current limit Arc I> of stage ARC S26
a)b)
1S26 2S26 0.50...35.0 x I
n
Current limit Arc I
0
> of stage ARC S27
a)b)
1S27 2S27 5.0...800% I
n
Checksum, SGF 1 S61 1S61 2S61 0...255
Checksum, SGF 2 S62 1S62 2S62 0...127
Checksum, SGF 3 S63 1S63 2S63 0...127
Checksum, SGF 4 S64 1S64 2S64 0...63
Checksum, SGF 5 S65 1S65 2S65 0...255
Checksum, SGB 1 S71 1S71 2S71 0...1048575
Checksum, SGB 2 S72 1S72 2S72 0...1048575
Checksum, SGB 3 S73
c)
1S73 2S73 0...1048575
Checksum, SGB 4 S74
c)
1S74 2S74 0...1048575
Checksum, SGB 5 S75
c)
1S75 2S75 0...1048575
Checksum, SGR 1 S81 1S81 2S81 0...8388607
Checksum, SGR 2 S82 1S82 2S82 0...8388607
Checksum, SGR 3 S83 1S83 2S83 0...8388607
Checksum, SGR 4 S84 1S84 2S84 0...8388607
Checksum, SGR 5 S85 1S85 2S85 0...8388607
Checksum, SGR 6 S86
c)
1S86 2S86 0...8388607
Checksum, SGR 7 S87
c)
1S87 2S87 0...8388607
Checksum, SGR 8 S88
c)
1S88 2S88 0...8388607
Checksum, SGL 1 S91 1S91 2S91 0...8388607
Checksum, SGL 2 S92 1S92 2S92 0...8388607
Checksum, SGL 3 S93 1S93 2S93 0...8388607
Checksum, SGL 4 S94 1S94 2S94 0...8388607
Checksum, SGL 5 S95 1S95 2S95 0...8388607
