ABB REF 610 - DNP 3.0 Device Profile

103
Description DNP point
address
Event class UR enable Deadband Value range
Number of AR shots (shot 1) initiated by
the digital input signal
11 3 1 1 0...255
Number of AR shots (shot 1) initiated by
the start or trip signal from stage I>
12 3 1 1 0...255
Number of AR shots (shot 1) initiated by
the start or trip signal from stage I
0
>
13 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the trip signal from stage I>>
14 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the digital input signal
15 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the start or trip signal from stage I>
16 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the start or trip signal from stage I
0
>
17 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the trip signal from stage I>>
18 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the digital input signal
19 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the start or trip signal from stage I>
20 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the start or trip signal from stage I
0
>
21 3 1 1 0...255
5.1.16.3. DNP 3.0 device profile
DNP V3.00
DEVICE PROFILE DOCUMENT
Vendor Name: ABB Oy, Distribution Automation, Vaasa, Finland
Device Name: REF 610
Highest DNP Level Supported Device Function
For Requests L
2
Slave
For Responses L
2
Notable objects, functions, and/or qualifiers supported in addition to the Highest DNP Levels
Supported (the complete list is described in the attached table):
Additions to level 2 are marked as shaded in the implementation table
Maximum Data Link Frame Size (octets) Maximum Application Fragment Size (octets)
Transmitted 292 Transmitted 2048
Received 292 Received 2048
Maximum Data Link Re-tries: Maximum Application Layer Re-tries:
Configurable, range from 0 to 255 with
primary data link layer retransmission count
Configurable, range from 0 to 255 with
application layer retransmission count
Requires Data Link Layer Confirmation:
Configurable, with confirmation type selector, default NO ACK
Requires Application Layer Confirmation
Configurable with confirmation type selector when reporting Event Data (Slave devices
only)
Always after response to reset request
Feeder Protection Relay
Technical Reference Manual
REF 610REF 610
1MRS755310
