Switchgroups
The relay contains the following switchgroups:
SGF1 Output contacts
SGF2 Display settings
SGF3, SGF4 Protection functions
SGF5 Latching feature for programmable LEDs
SGB1...SGB5 Digital inputs (DI1...DI5)
SGR1...SGR5 Output contacts (PO1, PO2, PO3, SO1, SO2)
SGL1...SGL8 Programmable LEDs
To set functions via switchgroups:
1. Press an arrow button to access the main menu.
2. Use the arrow buttons to select the main menu group SETTINGS and the wanted
switchgroup menu (for example SGF), and press
.
3. Use
or to select the wanted switchgroup (for example SGF2 for display
settings) and press
.
4. Use
or to select setting group 1 or 2 (GRP1 or GRP2). The active setting
group is indicated by an asterisk “*”.
5. Press
to enter the setting mode and give the password if required.
6. Use
or to select the bit to be set, and or to select the wanted bit
state, see Fig. 4.2.2.2.-4.
7. Press
to confirm the selection. After confirmation, the display returns to the
view mode and shows the checksum of the switchgroup.
8. Press
to return the display to the idle mode.
