45
WARNING
FAULT CODE: 2049
A040281
Fig. 4.3.2.3.-3 Warning with numeric code
Table 4.3.2.3.-2 Warning codes
Fault Weighting
factor
Description
Battery low 1 Description Battery voltage level low
*
Battery should be replaced
*
Warning will not be displayed if non-volatile
memory settings have been set to 0
*
In case only this warning is active, it will be
displayed in text format (BATTERY LOW)
Trip-circuit supervision 2 Error in trip circuit
*
Check the trip circuit for broken conductors and
correct.
*
Warning will not be displayed if trip-circuit
supervision (TCS) has been disabled
Power supply module
temperature high
4 Temperature inside relay is too high
*
Check that ambient temperature is within
service temperature range
Communication module
faulty or missing
8 Communication module faulty or not installed
*
Check that plug-in unit is properly attached to
relay case
*
Check that communication module is installed
*
Warning will not be displayed if rear
communication module has been disabled
*
In case only this warning is active, it will be
displayed in text format (Comm.card faulty)
RTD module faulty 16 Three possible causes:
1. Storing in non-volatile memory has not been
successful, which means that old settings
will be taken into use after power up
2. Self calibration has failed
3. Offset voltage out of range - If warning is not
cleared after a power reset, the relay may
require service
Temperature sensor range
error
32 At least one sensor (RTD1...6) is outside
measurement range
a)
*
Check that sensors are not broken
Sensor circuit open or
shorted (RTD1)
64 Circuit is open or shorted
a
*
Check wiring of sensor
*
Check that sensor is not broken
Sensor circuit open or
shorted (RTD2)
128 Circuit is open or shorted
a
*
Check wiring of sensor
*
Check that sensor is not broken
Motor Protection Relay
Operator's Manual - ANSI ve rsion
REM 610REM 610
1MRS755538
