32 | © 2019 ABB | 1SDH002039A1002 - ECN000093027 - Rev. A Interface and menus | 4 - Menu
Measurements Menu
Menu Submenus Description Page
Historicals
Trip Description in dedicated chapter 98
Events List of events recorded 98
Measurements
List and description in dedicated
chapter
98
Power factor
(1)
- Power factor measurement 101
Frequency
(1)
- Frequency measured 101
Energy
(1)
Energy counters Measurement of energies
101
Reset counters Meter reset command
Energy RESET
List and description in dedicated
chapter
101
Peak factor
(1)
- Peak factor of each phase 101
Harmonic dist. -
Activation command for current
harmonic distortion monitoring
48
Ekip
Synchrocheck
(2)
- Description in dedicated chapter 167
Network
Analyzer
(3)
V Sequences
Measurements associated with
Network Analyzer function: list and
description in dedicated chapter
107
3s V Sequences
THD Current
THD Voltages
Counters
Waveforms
Maintenance
Contact Wear
Installation and maintenance dates
and commands
117
LastServiceContactWear
Installation
Last Maintenance
Service RESET
(1)
available if provided for by Trip unit model or if SW Measuring Measurements package has been activated
(2)
available when Ekip Synchrocheck module is present
(3)
available if provided for by Trip unit model or if Network Analyzer SW package has been activated
