36 S4 D184B122U02
Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Contact output
No function
F/R-Signal /_
F/R-Signal __
General-Alarm /_
General-Alarm __
Max/Min Alarm/_
Max/Min Alarm __
Min Alarm /_
Min Alarm __
Max Alarm /_
Max Alarm __
Empty pipe /_
Empty pipe __
The switch status of the Contact Output
(Terminals 41/42) can be selected as nor-
mally open (/_) or normally closed (_ _). For
the "General-Alarm" all detected Errors (0-
6, A, B, C, D, F) are signaled over the termi-
nals. If a low flow condition is to be signaled,
then "Min-Alarm" should be selected. Simi-
larly a high flow condition is signaled when
"Max-Alarm" is selected. If the signal is set
for "Max/Min-Alarm" then a signal is sent
over the terminals when the flowrate is
above or below the range between the
"Max-Alarm" value and the "Min-Alarm"
value, i.e., when the flowrate is larger than
the "Max-Alarm" value or less than the "Min-
Alarm" value.
No function
Submenu
Label
view only
Pulse active no HART
Pulse active with
HART
Pulse passive no
HART
Pulse passive with
PROFIBUS PA
Variant error
Actu. Variant
Display of the pulse output and communi-
cation configuration for the shipped
design.ENTER Puls active no HART
Primary TAG Text entry
A TAG-Number to identify the flowmeter
primary max. 32-character can be entered
or read.„----------------------“
Converter TAG Text entry
A TAG-Number to identify the converter
max. 32-character can be entered or read.
„---------------------“
Submenu
Data Link
Communication
Without
HART
1. Communication HART
Set the HART Communication ON or OFF.
When HART-Communication is not re-
quired, Current Output ranges 0–20, 0–10,
2–10 mA can be selected. For HART-Com-
munication the Current Output range must
always be 4-20 mA. No entries possible for
Standard instruments (no HART-Hardware).
ENTER none
Instr. Address
numeric entry
0–15
For instruments using the HART-Protocol
an Address between 0-15 can be selected.
If the Address 0 is entered, then the Current
Output varies with flowrate in the range of
4-20 mA. If multiple instruments are con-
nected to the bus and an Address between
1 and 15 is assigned, then the converter
operates in the Multidrop-Mode. The Cur-
rent Output value is then constant at 4 mA.
The output values can then only be read
using the HART-Communication. Warning
11 is displayed.
No entries possible for Standard
instruments (no HART-Hardware).
