ABB SE21 series - Page 39

D184B122U02 S4 39
Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Contact input
Off
On
This memory is not displayed for PROFIBUS
PA.
Test the Contact Input. Before a signal is
applied to the Contact Input, the text "Off" is
displayed in this menu; after a signal is
applied the text "On" is displayed (to check
with a the simulator, use the Totalizer Reset
key).
Off
Contact output
Off
On
Test the Contact Output. Toggle the value
"On"/"Off" - the Contact Output condition
(open/closed) follows the settings selected
in the parameter "Progr. in/output " - "Con-
tact output".
Off
Display
Test the Display indications. Every point in
the dot matrix is activated one after the
other. After all points have been activated
the failure of a point is obvious.
Test Mode
Off
On
Only for checking the converter using
Simulator 55XC4000.
Off
Simulation Mode
Off
On
Turn the flowrate simulation On/Off. To
check the operation, a flowrate can be
simulated. The output values should
correspond to the equivalent of the simula-
ted flowrate value entered. In the lower line
of the display the message **Q Simulation**
is shown. After the simulation program is
completed, the parameter in the menu
"Simulation Mode" should be set to "Off".
Off
Simulation Value
numeric entry
-130 % – +130 %
In the process display the flowrate values
can be simulated by pressing the STEP or
DATA-Keys. The Current and Pulse Outputs
follow the simulated flowrate value.
0.0 %
Submenu
Status
After the Error Register is accessed, the text
"Error register" is displayed together with
the Quantity of errors set. Using ENTER
again the set errors with their Error Numbers
and descriptive text are displayed. Using
ENTER again the question is displayed if the
error is to be reset or if the Help text is to be
displayed. Using STEP it is possible to dis-
play all the set errors with their Error Number
and descriptive text. Using ENTER the set
errors can be reset.
Error register
ENTER Quantity 1
C (stored)
ENTER Ext. Data base
Reset: Enter
Help text: Step
0
Empty pipe
