SM500F
Field mountable paperless recorder Appendix B – Modbus TCP/Modbus 485
154 IM/SM500F Rev. Z
Read Only: 0 = Alarm group inactive
1 = Alarm group active
Read Only: 0 = Alarm group inactive
1 = Alarm group active
Title Coil Number Title Coil Number
Alarm Group 1 0751 Alarm Group 7 0757
Alarm Group 2 0752 Alarm Group 8 0758
Alarm Group 3 0753 Alarm Group 9 0759
Alarm Group 4 0754 Alarm Group 10 0760
Alarm Group 5 0755 Alarm Group 11 0761
Alarm Group 6 0756 Alarm Group 12 0762
Table B.8 Alarm Groups
Read Only: 0 = Real time alarm inactive
1 = Real time alarm active
Title Coil Number
Real Time Alarm 1 0851
Real Time Alarm 2 0852
Real Time Alarm 3 0853
Real Time Alarm 4 0854
Table B.9 Real Time Alarms
