Operation Manual / TPS48-D/E.. - TPS61-D/E..
Cleaning components mechanically
Page 69
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2410_EN Revision E
Cleaning the absorption segments
Loosen the tension bands (81270).
Remove the cover grid (81266).
Pull out the sheet-metal coverings (81137), bend them up and remove
the absorption segments (81136).
Clean the absorption segments (81136).
During cleaning, ensure that the absorption segments (81136) are only
cleaned with a mild jet of compressed air, soft brush or a damp cloth.
Have absorption segments which are heavily contaminated replaced
by an official ABB Turbocharging Service Station.
Fitting the filter silencer
Insert the absorption segments (81136) into the sheet-metal coverings
(81137).
Bend the sheet-metal coverings (81137) back into their original shape
and insert them into the slot guides in the silencer body (81135).
Fit the cover grid (81266).
Fit the tension bands (81270) and apply tension at the locks (81271).
Damaged tension bands must be replaced with new ones.
If provided, fit the filter ring (81265).
