TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION
1
TOUCH
About
HMI HMI serial number
Software version
Software subversion
HMI Type code
Controller Unit
Time
Date
Serial number
Normative
Controller software version
Controller software subversion
Automatic Transfer Switch
TAG name
ATS Type Code
ATS serial number
Rated current
Number of Poles
ATS Type
Modules (See Chapter 5, Electronic accessories)
Test *Default
On-Load Test Settings Initiate display test screen and turn all LED's on
Bypass Local Test Bypass if Gen. Fails*
Stay on Gen.
Bypass Remote Test Bypass if Gen. Fails*
Stay on Gen.
Test On Load Test generator with transferring the load. Test with
switch transfer.
Test Off Load Test generator without transferring the load. Test
without switch transfer.
HMI Test Initiate display test screen and turn all LEDs on.
Optional modules (See Chapter 5, Electronic accessories)
