4.2.1.3 Analog meters
TruONE ATS
Overviews
Main Menu Measures
Analog Meters
—
Fig. 4.16 By touching on Start Menu upper
right corner -image you can find the analog
meters information, see the table below
S1 Voltage meter
S2 Voltage meter
Current meter
Power meter
VAR meter
VA meter
