Transport and storage
Torch Service Center - TSC 2013 3HDA000057A8519-001 1-9
Assembly instructions
1.4 Transport and storage
1.4.1 General
1.4.2 Transport and packaging
Before dispatch by ABB, each TSC 2013 or separately ordered assembly is checked for damage
and completeness.
Protective packaging made of re-usable material is intended for transport.
The transport packaging is selected depending on the assembly to be supplied and number of
units (Table 1-1).
The TSC 2013 is packed singly lying in a carton.
Several units are screwed standing on a wooden pallet and protected by a wooden crate against
damage in transport.
The transport pallets are suitable for transporting with fork-lift truck.
Danger of injury due to unsuitable means of transport
and lifting implements.
The load must be adequately secured in transport"
Exercise great caution with the TC/TSC2013. Even
minor damage can have a substantial adverse impact
on function.
Do not throw, do not drop!
